Why Choose Us

Since 1999 we are committed to superior quality and customer service with the highest standards to meet customers requirement and satisfaction.

24

24

Prototype build
5

5

Days standard turnaround
24

24

Fast estimates
1999

1999

In business

Our services

Design
We are dedicated to provide most comprehensive design for your product at the shortest period of time using best available software and hardware solution on the market.
Read more
Layout
Our expertise in most comprehensive software and hardware tools makes ABC Assembly superior on stop shop from concept design to final product manufacturing and direct fulfillment to end customer.
Read more
Assembly
Advanced design to manufacturing expertise allows smooth transition from quick turn around prototype to mass production at no additional cost and time utilizing fast turnover high speed equipment.
Read more
Rework
Many years of experience and various advanced techniques makes possible to rework and repair components virtually any component size on the market with high precision of placement and soldering technology.
Read more
Wirebonding
Our semiconductor packaging capabilities include wide range of processes like precise dispensing, die placement, gold ball bonding, gold or aluminum wire or ribbon wedge bonding with tight control of pull and shear parameters.
Read more
Equipment
State of the art equipment allows us to expand our possibilities beyond the most complicated solutions and meet time to market expectation. From High Mix/Low volume to mass production capability allows to meet on time delivery and cost saving solution.
Read more

{{ title }}

HARDWARE

  • System level engineering and analysis
  • Research, Selection and Validation of
    electronic components
  • Processing MCU – ARM Cortex/STM32
    /SiLabs/TI
  • Communication – BLE/WIFI/Ethernet
    /LORA-WAN/ZeegBee/GSM/M-BUS/GPS/GNSS
  • Sensors – Camera/Temperature/EKG/PPG/Magnetic
    /Light/Moisture/9 axis accelerometer
  • Embedded UI/UX design

FIRMWARE

  • Embedded Linux
  • C/C++
  • GC Power Place

LAYOUT TOOLS

  • Electrical – OrCAD, PCAD, PADS, Cadence ALLEGRO
  • Mechanical – AutoCAD, 3D Solidworks
  • ProTel
  • ViewLogic

SIMULATION TOOLS

  • ModalTek (Verilog verification)
  • Eagleware (RF!)
  • 5 Fully Automated hight speed SMT lines
  • SMT: 00501, BGA, MicroBGA, CSP’S, Flip Chips
  • Pin Through Hole
  • High Density Press Fit connectors
  • Stencil-less jet solder printing technology
  • No clean and water soluble process
  • 13 Zone Nitrogen Convection Reflow
  • 3D X-Ray inspection
  • Automatic Optical Inspection
  • Cable Assembly
  • Wave Soldering TH Process
  • Box Build
  • Custom process development
  • Complete system integration
  • High Volume, Quick Turn BGA, PBGA, CBGA, CSP, LGA
  • Rework & Inspection
  • BGA, CCGA, CBGA, and Micro BGA Component Reballing
  • Customized Component and Board Reflow Process Development
  • Component underfill
  • Mandatory baking and dry air enviroment
  • Complete automation for repeatability
  • IR monitoring of the temperature profile
  • PCB and traces repair
  • Clean Room Enviroment
  • Automatic Die Placement
  • Mandatory Plasma Cleaning
  • Thermal and Electro Conductive die bounding
  • Precision dispensing
  • Online and off line Programming
  • High Speed Gold Ball Wirebonding
  • Pull and Shear Test
  • Encapsulation
  • Wire and Ribbon (up to 10 mil) wedge bonding
  • Mydata My200SX-14 Inline
  • Mydata My100SX-14 Inline
  • Mydata My15e Inline x 2
  • Mydata My12e Inline
  • Mydata My500 Jet Printer x 3
  • Heller 1913 MKIII Nitrogen Reflow x 2
  • X-TEK 3D X-RAY
  • Teradyne 1525 X-Ray
  • Mirtec AOI system
  • Airvac Onyx 29 Rework
  • Aircav Onyx 32 Rework x 2
  • Airvac DRS 25 Rework
  • ERSA BGA Inspection System
  • Electrovert Econopack Gold Wave solder
  • Triton no clean cleaner
  • N2 Nitrogen generator
  • K&S Connx Wsirebonder x 2
  • K&S 8068 Ribbon bonder x 2
  • Plasma Cleaner
  • Vacuum batch ovens
  • Dage 4000 Sheer and Pull tester
  • Various FIFO/LIFO, inspection and other conveyors
  • Various inspection microscopes
  • Various TH insertion machines
  • Various soldering tools

Instant Quote

Full feature prototype PCB custom service at low cost.

{{ errorMessage }}

Please leave your contact here

{{ errorMessage }}
Thank You!
Our managers will contact with you in 24 hours.

{{title}}

{{text_link}}

Virtual tour

Our customers

ABC Assembly holds multiple certifications which allows to implement knowledge and experience in various fields including Medical, Military, Semiconductor, Consumer, Test and many other industries. Long term relationship with the customer is being developed through hard work, quality assurance and on time delivery. Individual approach to each project regardless of size and lifespan, allows to maintain high standard craftsmanship and customer service.
